Innovative Laser Driver Circuit Pushes Current Limits for High-Power Pulses
An innovative laser driver circuit has been developed, utilising an NPN transistor in avalanche mode to generate high current pulses through a laser diode. This circuit, protected by an optoisolator, successfully drove the laser diode without damage, producing pulses estimated at 30 to 40 watts.
The circuit, detailed in an article, employs a buck-boost converter to increase the power supply from 12 volts to 200 volts. It includes a pulse-shaping network of resistors and capacitors, along with a current monitor using low-value resistors. The driver operates at a pulse frequency of 360 hertz, creating a visual beating effect due to slight mismatches between driver and camera frame rates.
The driver treats current limits on electronic components as mere suggestions for nanosecond durations, pushing the boundaries of conventional electronics. This approach is not new, as previous laser drivers have utilised avalanche breakdown for short, high-power pulses. However, the specific inventor or originator of this pulse frequency modulated laser driver with 'avalanche breakdown operation' for short, high-current pulses remains unclear, as it does not appear to be widely attributed to a specific individual.
The pulsed laser driver circuit, developed by Aled Cuda, demonstrates the potential of treating current limits as mere suggestions for nanosecond durations. While the specific inventor of this technique is not widely known, the use of avalanche breakdown for short, high-power pulses is not new in laser technology. Further research in this area could lead to advancements in high-speed electronics and laser applications.
