Electronic Support Measures (ESM) refer to a set of electronic equipment and techniques designed to locate, intercept, identify, and analyze electromagnetic signals emitted by hostile electronic systems.

Electronic Support Measures (ESM) refer to a set of electronic equipment and techniques designed to locate, intercept, identify, and analyze electromagnetic signals emitted by hostile electronic systems.

In the realm of drone technology, Electronic Support Measures (ESM) have become a crucial component, enhancing safety and mission outcomes without revealing the drone's presence.

ESM is a technology designed to detect, analyze, and locate electromagnetic signals. It works passively, listening to signals without transmitting, thus maintaining stealth. This makes it particularly useful in contested or hostile environments.

The system undergoes four key steps: detection, classification, direction finding, and geolocation. ESM sensors continuously scan the electromagnetic spectrum to detect emitted signals from potential targets such as radar installations, communication hubs, or tracking systems. By measuring characteristics such as frequency, pulse repetition interval, scan patterns, modulation, and waveform features, the ESM system determines the type of radar or communication emitter and often identifies the platform using it.

Using antenna arrays or multiple sensors, the ESM system performs direction finding (DF) to determine the bearing of signals. When combined with platform movement or multiple sensor data, it can triangulate the position of the emitter. This information is vital for tactical situational awareness and electronic intelligence (ELINT).

Modern ESM systems, like Saab’s naval ESM and ELINT solutions or the Sirius Compact C-ESM, integrate advanced algorithms for rapid automatic detection, classification, signal library management, multi-path cancellation, and low probability of intercept detection. These enhancements make them indispensable in contested environments.

Outside the military, similar passive monitoring techniques are also gaining interest in commercial airspace management and counter-UAS applications. For instance, Jacob Stoner, the CEO of Flyeye.io, a licensed commercial drone operator in Canada with a passion for drone technology and videography, is exploring the potential of ESM in commercial drone operations.

It's essential to note that ESM is different from Electronic Countermeasures (ECM), which actively jam or deceive signals. While ESM provides electronic intelligence, ECM is used to protect friendly forces from threats. In electronic warfare scenarios, these two technologies are often used together.

In a border patrol mission, a reconnaissance drone uses passive ESM to detect an unfamiliar radar system. The drone's system calculates the exact location of the radar by analyzing signal patterns and direction. This information, shared with command, allows them to adjust the drone's flight path and alert manned aircraft nearby, enhancing safety and mission success.

In conclusion, ESM systems function as passive electronic intelligence sensors that detect, classify, and locate electromagnetic signal sources by measuring and analyzing their unique emission patterns and directions without revealing their own presence. This technology has become a cornerstone of modern drone warfare and surveillance.

Data-and-cloud-computing technologies are increasingly being integrated with ESM systems to improve threat detection capabilities.

The enhancement of ESM systems, such as Saab’s naval ESM and ELINT solutions, with data-and-cloud-computing technology enables real-time analysis and sharing of critical information from threats detected, improving situational awareness and mission outcomes.
