Alterations in Interframe Gap (IFG) and Their Impacts on Operation Modes

Alterations in Interframe Gap (IFG) and Their Impacts on Operation Modes

In the realm of industrial and real-time Ethernet applications, the Analog Devices FIDO52x0 real-time Ethernet switch stands out for its reliability and efficiency. A crucial aspect of its operation is the management of Interframe Gaps (IFG), which plays a significant role in ensuring proper timing, avoiding frame collisions, and preventing frame drops.

According to Analog Devices use cases and reference designs, the key recommendation is to set the software or switch IFG value to 12 bytes (96 bit-times) per Ethernet standard. This standard IFG is essential for the switch to process and forward frames without dropping or corrupting them. Deviating from this standard (for instance, using a smaller IFG) can lead to frame overlaps and timing violations, potentially causing frame drops.

Here's a summary of the recommended configuration:

| Parameter | Recommended Value | Reason | |------------------------|-----------------------|-----------------------------------| | Interframe Gap (IFG) | 12 bytes (96 bit-times) | Compliance with Ethernet spec; ensures no frame drops and proper frame timing |

This configuration has been demonstrated in Analog Devices application notes and evaluation software examples, ensuring smooth real-time frame handling and system stability.

The FIDO52x0's MAC detects the rising edge of RX_DV and the start of frame delimiter (SFD). It's important to note that there is a potential for a +0/-1 RXCLK time (40ns) jitter relative to the 125MHz clock phase.

Packet processing in the FIDO52x0 occurs in the 125MHz system clock space. The outgoing data in the FIDO52x0 is synchronized into the TXCLK (25MHz) space, while the RXCLK and RX_DV signals are synchronized into the 125MHz clock space. If the RX IFG is less than the configured value, the switch drops the frame automatically. The minimum gap between outgoing packets can be configured using the TX IFG register, and the outgoing IFG is not less than the value in the TX IFG register.

The FIDO52x0 supports various real-time Ethernet protocols such as EtherCAT, PROFINET real-time, isochronous real-time, EtherNet/IP, Modbus TCP, and POWER-LINK. It also supports various Layer 2 or Layer 3 protocols. The switch is capable of handling throughputs of 10Mbps/100Mbps.

In case of issues with frame drops, reconfiguring the RX IFG and TX IFG registers can help resolve the problem. It's worth mentioning that in a network with 87 devices, frame drop issues were observed and successfully addressed by adjusting these registers.

The FIDO52x0 is a real-time Ethernet, multiprotocol switch, and it comes with software drivers for each supported protocol. It's essential to consult the FIDO52x0 user manual or specific design files from Analog Devices for detailed guidance on Ethernet or MAC timing, often with example register settings or PHY interface configurations to maintain the 12-byte IFG.

Technology plays a vital role in setting the Interframe Gap (IFG) value for the Analog Devices FIDO52x0 real-time Ethernet switch, which is recommended to be set to 12 bytes (96 bit-times) per Ethernet standard. This configuration, done through data-and-cloud-computing tools like software or switch settings, ensures the switch processes and forwards frames without dropping or corrupting them.
