A Simple Guide to Upgrading Your Power Supply System
Easily Revamp Your Broadcast Equipment's Power Supply in a Snap!
Hey there! Ever found yourself in a pickle with a faulty power supply in your broadcast equipment? Worry not! Frank Hertel, our high-tech troubleshooter, has got your back with a nifty trick to retrofit your internal power supply with a bunch of external power bricks. Let's dive in!
Frank's client was sieged by a DMX Mix console with a busted internal switch mode power supply that provided the essential +15 and -15 VDC. To minimize the downtime, Frank came up with a genius idea to add some power bricks to the mix!
Here's what you'll need for this simple hack:
- Two off-the-shelf 15 VDC power brick supplies, one providing +15 VDC and the other handing over –15 VDC.
- The original internal power supply cable, ready for some adapting.
First things first, remove the gunky old internal power supply and its jumper cable. Carefully note the polarities, colors, and connections.
Now, it's time for some cable surgery. Cut the original jumper cable in half and extend each of the colored wires to a length of 18 inches. This will provide plenty of play for connecting them to the fresh power brick supplies.
After a quick rewire, you'll soon be connecting your new power brick aces to the motherboard. Pay attention to the wiring of the 3.5 mm female connectors; they'll route the appropriate DC voltages to the mother board, just like magic!
Fancying a more organized setup? Why not construct a friendly junction box for your new power brick pals? It'll tie the two supplies together, and you'll only need one AC power cable to light up your broadcast equipment.
Now, lay those power bricks on top of the chassis - it might not be fancy, but it's convenient as heck! Plus, it'll make swapping out failed supplies a breeze when the need arises.
Have you tried this trick with your own broadcast equipment? Spill the beans! Drop us a line at [email protected] and encourage your fellow audiophiles to give it a shot!
Happy broadcasting, folks!
*[Check Out Another John Bisset's Workbench]***
In this creative fix masterminded by Frank Hertel, he suggested utilizing two external power bricks to replace the faulty internal switch mode power supply in a DMX Mix console, ensuring the correct +15 and -15 VDC are provided. This smart adjustment, involving gadgets like the power bricks, could be a perfect solution for many in the industry who face similar power supply issues, aligning with data-and-cloud-computing and technology advancements.
With the help of the original internal power supply cable, it's now possible to retrofit the external power bricks to the broadcast equipment, making it a simple yet effective way to keep the technology up to speed during emergencies in the broadcasting world.
